TIP For the safety of the electronics on the Arduino and MaxBotix ultrasonic sensors, please use an ESD strap when working around components. Static discharge could damage components of the Arduino as well as the ultrasonic sensors. Arduino (the Ultimate Starter Kit is a great choice for beginners).Jumpers (included in the Ultimate Starter Kit).MaxBotix ultrasonic sensor with AN or PW output.Soldering iron and solder (optionally use spring loaded test leads to avoid soldering).Breadboard (optional and included in the Ultimate Starter Kit).This article assumes you have the required equipment and necessary skill to operate a soldering iron. However, springloaded clip leads could certainly be used for solder free testing.ġ. Install the Arduino Sketch software on your computer New users may wish to follow one of the wiring diagrams included in this tutorial. You can connect the ultrasonic sensor directly to the Arduino with wires or use a breadboard. Attaching a 90-degree header to the ultrasonic sensor makes it very easy to attach it to a breadboard.īreadboard – A thin plastic board used to hold electronic components (transistors, resistors, chips, etc.) that are wired together.
Used to develop prototypes of electronic circuits, the boards can be reused for future jobs.ģ. Please allow time for the computer to install the Arduino drivers. Wiring Images How to Code Sensors in Arduino Arduino Coding: Part 1 Useful Informationīreadboard – A thin plastic board used to hold electronic components (transistors, resistors, chips, etc.) that are wired together.
Used to develop prototypes of electronic circuits, the boards can be reused for future jobs. An image of how the internal nodes are connect is viewable hereĪDC – Analog to Digital Converter.
